Model Engineer Magazine - 4665

In this issue

Peter Seymour-Howell finishes off work on his 5 inch gauge Flying Scotsman tender by adding the brake cylinders and vacuum reservoir. Adrian Garner explains the design principles for his astronomical bracket clock and makes a start on construction. Geoff Stait and Chris Deith remember the life of David Piddington. Jacques Maurel explains how you can broach polygonal holes and presents a tool for achieving a good result. Keith Rogers builds Jan Ridders’s four stroke single cylinder internal combustion engine. Luker completes the construction of his American outline 4-4-0 5 inch gauge locomotive by making the body for the tender. Ron Fitzgerald traces the development of the textile mill engine in Yorkshire. Jason Bellamy adds the piston, guide bars and crosshead to his Thompstone mill engine. Noel Shelley ponders the difference between a cunning replica and an out-an-out fake. Rhys Owen looks at the science and technology behind the important business of lubricating a steam engine. John Arrowsmith visits the Wakefield Society of Model and Experimental Engineers and sees for himself how the track has developed and grown since the club’s foundation. Ian Martin sheds more light on a modern approach to Computer Aided Design, making use of parametric design.
